IP kamera Hikvision DS-2CD2347G2-L (2.8 mm), 4MP, ColorVu

Trumpai apie prekę

Prekė: IP kamera Hikvision DS-2CD2347G2-L (2.8 mm), 4MP, ColorVu. Kategorija: IP kameros.

• Gamintojas: Hikvision
• Modelis: Hik DS-2CD2347G2-LU(2.8MM)(C)

1,053.55

DS-2CD2347G2-L(2.8M

IP camera with efficient H.265 / H.264 image compression algorithm ensuring clearer and smoother image transmission at a maximum resolution of 4 MPx

The ability to power via PoE, in accordance with the 802.3af standard, makes the device even more versatile and easier to install

The camera meets the IP67 tightness class

Attention!

The ColorVu series camera does not have a black and white mode

Thanks to the camera being equipped with a highly sensitive transducer and an LED illuminator emitting visible white light, the device allows for obtaining a clear, colorful image in all lighting conditions.

Standard:

TCP/IP

Converter:

1/1.8 " Progressive Scan CMOS

Scanning system:

Progressive

Matrix size:

4 Mpx

Resolution:

2688 x 1520 - 4 Mpx,

1920 x 1080 - 1080p

1280 x 720 - 720p

Lens:

2.8 mm

Viewing angle:

• 109 ° (manufacturer's data)
• 102 ° (our tests)

White light illuminator range (LED):

30 m

Memory card slot:

Micro SD card support up to 256GB (local storage possible)

Image compression method:

H.265+ / H.265 / H.264+ / H.264 / MJPEG

Alarm inputs/outputs:

Audio:

Main stream bit rate:

25 fps @ 4 Mpx

Network interface:

10/100 Base-T (RJ-45)

Network protocols:

TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, NTP, UPnP, SMTP, IGMP, IEEE 802.1x, QoS, IPv4/IPv6, UDP, Bonjour, SSL / TLS, PPPoE, SNMP

WEB Server:

Built-in

Max. number of online users:

6

ONVIF:

18/12

Selected functions:

• Possibility to turn off the LED illuminator
• WDR - 130 dB - Wide dynamic range of lighting
• 3D-DNR - Digital image noise reduction
• ROI - improving the quality of selected image fragments
• Anti-Flicker - Technology that eliminates the eye-straining effect of image flickering
• BLC - backlight compensation (backlight)
• HLC - High Light Compensation (Spot)
• Possibility to change resolution, quality and bandwidth
• Mirror - Mirroring the image
• Motion detection
• Configurable privacy zones
• Sharpness - Sharpening image contours
• Filtering false alarms based on person and vehicle recognition
• Video tamper detection
• Intelligent image analysis: line crossing, intrusion, scene changing, area entry/exit detection, face detection

Access from mobile phone:

• Port: 8000 or access via cloud (P2P)
• Android: Free iVMS-4500 or Hik-Connect app
• iOS (iPhone): Free iVMS-4500 or Hik-Connect app

Default IP address:

192.168.1.64

Default administrator login/password:

admin / -

The administrator password must be set on first startup.

Web access ports:

80

Access ports via PC application:

Port: 8000 or access via cloud (P2P) - iVMS-4200 application

Access port via mobile app:

8000

ONVIF port:

80

RTSP URL:

• Main stream: rtsp://user:password@192.168.1.64:554/Streaming/Channels/101/
• Substream: rtsp://user:password@192.168.1.64:554/Streaming/Channels/102/

Power supply:

• PoE (802.3af),
• 12V DC / 550mA

Power consumption:

? 7.6W @ PoE

? 6.6 W @ 12 VDC

Case:

Dome, Aluminum + Plastic

Color:

White

Tightness class:

IP67

Vandal-proof:

Operating temperature:

-30 °C ... 60 °C

Libra:

0.78 kg

Dimensions:

Ø 139 x 125 mm

Supported languages:

Polish , Bulgarian, Croatian, Czech, Danish, Estonian, Finnish, French, Greek, Spanish, Dutch, Lithuanian, Latvian, German, Norwegian, Polish, Portuguese, Russian, Romanian, Serbian, Slovak, Slovenian, Swedish, Turkish, Hungarian, Italian

Manufacturer / Brand:

Hikvision

SAP Code:

311315181

3

CE

EN catalog card

EN Instructions

Instructions for adding devices to the mobile application (Android) PL

Instructions for adding devices to the mobile application (iOS) PL

Date act

Specifications

Group	Name	Value
Parametry	Condition	new
Parametry	Invoice	With VAT invoice
Parametry	Product weight with unit packaging	0.8 kg
Parametry	EAN (GTIN)	6941264083580
Parametry	Manufacturer code	Czarna DS-2CD2347G2-LU(2.8MM)(C)(BLACK)
Parametry	Brand	Hikvision
Parametry	Model	Hik DS-2CD2347G2-LU(2.8MM)(C)
Parametry	Packaging status	original
Parametry	Batteries included	no
